"HUSH High Flow"- Model DTHHF-1500

So quiet you can hear yourself think.

Standard Equipment

  • 27-8" x 60" Upper Filters are standard
  • 3 Plastic Collection Bags
  • Snap-Band Tight Seal Filters
  • Motor & Three Filter Sections - Standard -
  • 3 Quick Release Metal Straps
  • Internal Return Feature That Reduces Heat Loss to Zero
  • Impeller Housing Latch System
  • Unique Baffling System for Even Bag Filling
  • Three Position Height Adjustment "StongLeg" System
  • Five Year Comprehensive Warranty

Specifications

  • Inlet Diameter - 14" or 16"
  • Storage Capacity* - 60
  • Filter Area** - 132
  • CFM - 4,950   *Complies with NFPA #664-12 Fire Code
  • 14" of W.G. static suction strength
  • Amps 208 Three Phase - 40
  • Amps 230 Three Phase - 37
  • Amps 460 Three Phase - 19.5
  • Height - with 8" x 48" upper filters = 124" tall - Standard
  •                with 8" x 60" upper filters = 136" tall
  •                with 8" x 84" upper filters = 160" tall
  •                with 8" x 96" upper filters = 172" tall
  • Width of body - 33" Width of motor section - 41"
  • Length - 124"
  • Height From Floor to Cone Opening-Highest Mount - 84.25"
  • Net Weight - 1250 lbs
  • Crated Weight - 1475 lbs

*Storage Area Measured in Cubic Feet

**Filter Area Measured in Square Feet

***Magnetic Starter is Optional and Extra

****Additional 9 Tube Sections are Available - Please consult our office
